TeamCity 7.1 Branch Builds Rock

I’ve been using TeamCity as my CI server of choice for years now because the folks at JetBrains just keep making it better.  Branch builds are just another example of the kind of thoughtful goodness I have come to expect from these guys.

It’s all designed to fix a problem that occurs when a team takes advantage of the power of a DVCS system like Git or Mercurial.  When a developer starts working on a feature, he or she makes a local feature branch that gets pushed to the main repository periodically.  Once the feature is done, the branch is merged into the main development branch.  Traditionally, the CI server is configured to build the main development branch.  That means developers lose the benefit of all the checks the CI server does whenever they are working on a feature branch.

It gets even worse when you have multiple team members collaborating on feature branches or working on closely related feature branches.   For example, Mark checks in Feature X that Mary would like to merge with her work.  The problem is she has no way to know the code in Feature X passes tests or even compiles before she pulls it down to her local machine.  If it is broken, she ends up wasting valuable time on something she probably should not have tried to merge in the first place.

TeamCity solves this by allowing you to setup your configuration to automatically build all or selected active branches without treating them like they are supposed to be stable.  Although TeamCity shows their status, broken feature branches do not impact the overall project status; As long as the main branch builds and passes all tests, the project status will still be good.

Setup could not be easier especially if you just want to build all feature branches.  You simply go to the VCS root and configure which branches you want to build as shown here:

The specification “+:*” tells TeamCity to build all branches automatically.

Once you do this, you’ll start seeing branch names next to the builds on the main screen.  You can also see a screen with a summary of the state of each branch like this:

Very useful indeed.

TeamCity Professional is free if you have fewer than 20 build configurations.  It includes three free build agents.  If you need more than 20 build configurations or you need Active Directory integrated security, the Enterprise edition is $1,999.  Additional build agents cost $299 each.  You can see the complete price list and license details on the TeamCity web site.

Nant Task to Synchronize Scripts Folder to Database Using RedGate SQL Compare API

Redgate’s SQL Compare is an indispensable tool for anyone doing development against Microsoft SQL Server.  It’s ability to export the database structure to a scripts folder and then synchronize changes from a database back to the scripts folder is a its greatest feature; It allows the database structure to be placed under source control with a high degree of granularity since each database object becomes a script file.

Our build process includes a step to deploy a test/demo version of our web to a server.  As part of that process, we need to update the database structure from the scripts folder.  Thanks to the SQL Compare API that was included with RedGate’s SQL Toolbelt, I was able to put together an NAnt task that does the job.  Here is the actual Nant target from our build script:

<target name="updateDatabaseStructure">
    <schemaSync sourceScriptsPath="${project.dir}\db\OnpointConnect"  destinationServerName="${sqlServerInstance}" destinationDbName="OnpointConnect"/>
</target>

You’ll notice the target uses a couple of properties to point at the location of the project root (${project.dir}) and the SQL Server instance name (${sqlServerInstance}).  Since the task does not specify a user name and password, the schemaSync task uses the Windows security credentials of the user running the build to logon to the database.  In the case of our automated build, the user account that runs the build process has access to the database.  You can change to a SQL Server login by providing sourceDbUserName and sourceDbPassword properties to schemaSync.

The complete list of supported attributes is as follows:

Attribute Description
sourceServerName If synchronizing from a database, the name of the source database server.
sourceDbName If synchronizing from a database, the name of the source database.
sourceDbUserName If using SQL Server authentication, the name of the user in the source database.  Omit this attribute to use Windows authentication.
sourceDbPassword If using SQL Server authentication, the password of the user in the source database.  Omit this attribute to use Windows authentication.
sourceScriptsPath If synchronizing from a scripts folder, the path to the scripts folder.
destinationServerName The name of the server to synchronize to.  REQUIRED.
destinationDbname The name of the database to synchronize to.  REQUIRED.
destinationDbUserName If using SQL Server authentication, the name of the user in the destination database.  Omit this attribute to use Windows authentication.
destinationDbPassword If using SQL Server authentication, the password of the user in the destination database.  Omit this attribute to use Windows authentication.

You can download the source code from my GitHub SouthSideDevToys repository.

RedGate’s licensing will require you to purchase the SQL Comparison SDK after a demo period.  At this time, the product sells for $695 and you should be able to get a 15 day demo from RedGate.

The code is fairly self-explanatory.  I wrapped an Nant task around a set of classes that works with the API.  The Nant task assumes that the destination will always be a database even though the underlying code is capable of synchronizing to a scripts folder.  If you have questions about the code, feel free to comment and I will respond with more information.

RedGate just released Data Compare 8.0 that allows data comparisons and synchronization with scripts.  RedGate says that the next version of their API, due out at the end of August 2009 (UPDATE: Can be obtained by licensed customers through support), will include this capability as well.  Our database includes configuration data that we currently rollout via SQL scripts.  This process is a pain to maintain because each time the data changes we have to update our scripts and test them.  As soon as RedGate’s new API becomes available I plan to change this process to use Data Compare via Nant so that everything is automatic.  I’ll publish the Nant task as soon as I have it working.
